Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.) ( en Inventor James Vandervalk Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.) Granted Application number CA2191692A Other languages French ( fr) Ten different settings allow producers to be in control of processing speed and material size.Īdjustments to three tub walls and a shortened discharge chute.ĭesigned to help optimize bale rotation and feeding and minimize plugs.- Google Patents CA2191692A1 - Bale processor Optional square bale kit gives you the ability to process large square bales in addition to round bales.ĭual adjustments can now be made on the cut control bar from the outside of the machine. Optional square bale kit including straight forks and optional powered sidewall. Split shafts let you perform maintenance without removing the entire bed. Heavy-duty sprockets and chains allow misshaped bales to be processed more smoothly. The slat and chain bale rotation design feeds bales more consistently into the rotor, reducing the need for reverse rotation. The curtain can be raised to broadcast up to 50 ft (15.2 m).įeeds bale consistently into the rotor – reducing the need for reverse rotation. The unique rubber curtain helps minimize spillage from the back of the machine, with the ability to consistently feed over a 32 in (81.3 cm) feed bunk wall. Rubber curtain at the backside of the machine and at discharge. Right-side discharge located on the same side as most tractor hydraulic controls gives the operator visibility. Process whole bales of varying shapes (with a powered side-wall kit) and qualities to produce uniform windrows, hit tight spots along the bunk line or spread evenly up to 50 ft (15.2 m) for bedding.ĭischarge located on same side as tractor hydraulic controls. Rotates and pulls material preventing fall-through.Īn offset rotor rotates and pulls material through for more consistent feeding and helps prevent uncontrolled fall-through from slowing down the machine. The design allows operators to expect less maintenance and helps increase durability and efficiency when compared to chain or belt driven processors. Plus, the robust T-style tongue frame has no welds or gussets at high stress points and is bolted high on the tub, helping enhance durability.
T-style frame with heavy-duty feed system.Ī vertical bale lift system makes it more efficient to load bales and help reduce stress on the machine. Weldment attached to the cut control bars to help manage build-up of net or twine left on the rotor.Īllows producer to help reduce build-up of net or twine on the rotor or to help minimize the amount of net or twine in the feed.
